FAST-EM

Transform your biological research with large-area imaging at the nanoscale

Capture large areas of thin sections from biological samples at unprecedented speeds and high resolution. Uncover both sub-organelle details and the broader tissue context, enabling statistical evaluations for novel and reliable insights.

Get in touch

Get specifications

Obtain more quantitative insights

Easily obtain nanometer resolution details over larger areas using FAST-EM, a high-throughput automated multibeam electron microscope. Transform your research from qualitative to quantitative and obtain more reliable insights by taking sample heterogeneity into account. Explore the sub-organelle details of healthy and diseased tissues, analyze organisms at different development phases, or visualize the effects of gene therapies.

Get in touch

Advantages of FAST-EM

Image large areas faster with high-resolution

Study both tissue contexts and ultrastructure details

Boost your research with novel reliable insights

Capture larger volumes for vEM

Capture larger volumes in a significantly shorter timespan in your volume-electron microscopy (vEM) workflow using FAST-EM. Open doors to ambitious and ever-larger projects. What questions would you be able to answer from the full connectome of a model organism, a 3D atlas of a zebrafish, or a full volumetric survey of a tumor?

Ultra-fast multibeam acquisition

Using state-of-the-art optical Scanning Transmission Electron Microscopy (STEM) and sample collection on scintillators, FAST-EM can employ 64 electron beams scanned in parallel over the sample. This innovative approach significantly speeds up the image acquisition time, ensuring fast and efficient data collection. Coupled with automatic stitching, you can study the context and ultrastructural details of your sample all at once.

User-friendly and automated operation

Designed in collaboration with ThermoFisher, Technolution, and TU Delft, FAST-EM transforms the electron microscopy workflows. The image quality, reliability, and degree of automation enable you to shift your focus microscope operation to extract meaningful conclusions from your data using CATMAID and Webknossos as compatible data viewing platforms.

Results

Imaging with FAST-EM

Malota-annelid-worm-tissue_scalebar_10um

Pathology

FAST-EM image of a human airway epithelial (HAE) cell layer infected with the Omicron variant of SARS-CoV-2. Scale bar: 10 μm. Sample courtesy of Thomas Burgoyne and Andreia Pinto (University College London, UK)

Cell biology

Zebrafish of ~105 hpf imaged at a 4 nm pixel size, providing a context of different organs and the possibility to zoom into sub-organelle morphological details. Scalebar: 50 μm. Sample courtesy of Peter Duinkerken and Ben Giepmans (University Medical Center Groningen, NL), Arent Kievits, Elizabeth Caroll, and Jacob Hoogenboom (Technical University of Delft, NL).

Cell biology

Mitochondria in the rat kidney automatically segmented using a finetuned MitoNet, Empanada. Scale bar: 10 μm. Sample courtesy of Nalan Liv (University of Utrecht, NL).

Pathology

Field image of rat pancreas. Data captured using FAST-EM. Scalebar: 10 μm. Sample courtesty of B.N.G. Giepmans and P. de Boer (UMCG).

Developmental biology

Annelid worm tissue –OTO stained. Scale bar: 10 μm. Sample courtesy of Karol Malota (University of Silesia, PL)

Neuroscience

Mouse brain with cross sections of neurons. Scale bar: 20 μm. Sample courtesy of Jeff Lichtman group & R. Schalek (Harvard University, US).

Interested to learn how FAST-EM expands the insights into infectious diseases?

Read application note

Interested to you can accelerate quantitative assessments with deep learning?

Read whitepaper

Interested to learn how you can speed up your research with innovative automated sample preparation?

Read whitepaper

Interested to learn how you can speed up your research with innovative automated sample preparation?

Read whitepaper

Interested?

Explore your options

Reach out to our team of specialists to find out how our solutions can help you advance your research towards a next breakthrough.

Get in touch

Customers

Trusted by researchers in the field

“With FAST-EM, we can go to larger volumes. For instance, it could be used for a full model animal brain to map out all the neurons' connections.”

Dr. Jacob P. Hoogenboom Faculty of Applied Sciences, TU Delft

“We typically don’t take 3D images because if you have a large area, it takes us 6 hours for one 2D image. If you want to have a thousand sections, it will take a year. If you now have a very fast microscope, we can go for 3D imaging within a week of such a section.”

Ben Giepmans, Principal Investigator University Medical Center Groningen
